| Item | Unit | Parameter | ||
| Working performance | Washing operation | Max washing width | mm | 4100 |
| Washing speed | km/h | 3~20 | ||
| Rated pressure of cleaning water | Mpa | 10 | ||
| Rated flow of cleaning water | L/min | 130 | ||
| Sweeping work | Sweeping width | m | 3510 | |
| Sweeping speed | km/h | 3~20 | ||
| Cleaning speed | km/h | 3~20 | ||
| Max cleaning capacity | m2/h | 82000 | ||
| Plane cleaning width on the curb | mm | 220 | ||
| Angle of unloading | (.) | ≥50 | ||
| Maximum inhalation of granularity(equivalent diameter) | mm | 90 | ||
| Volume of water tank | m3 | 9.1 | ||
| Volume of dustbin tank | m3 | 7.5 | ||
| Driving performance | Max speed (full load) | km/h | 90 | |
| Max gradeability | % | 30 | ||
| Braking distance (full load 30km/h) | m | 10 | ||
| Min turning diameter | m | 14 | ||
| Fuel consumption | Fuel consumption per 100 kilometers under restricted conditions | L/100km | 17.8 | |
| Full wash and sweep operation | Auxiliary engine speed 1700r/min | L/h | 16.1 | |
| Operating speed | L/10000m2 | 5.6 | ||
| 7km/h | Auxiliary engine speed 1500r/min | L/h | 14.2 | |
| (2nd gear idling) | L/10000m2 | 3.74 | ||
| Full sweep | Auxiliary engine speed 1700r/min | L/h | 16.8 | |
| Operating speed | L/10000m2 | 4.56 | ||
| 7km/h | Auxiliary engine speed 1500r/min | L/h | 12.1 | |
| (2nd gear idling) | L/10000m2 | 3.11 | ||
| Weight parameter | Tare Weight | kg | 11500 | |
| Max.Gross Weight | kg | 18000 | ||
| Dimension parameter | Dimensions (length x width x height) | mm | 8580x2490x3100 | |
| Wheel base | mm | 5000 | ||
| Track | Front wheel | mm | 1880 | |
| rear wheel | mm | 1860 | ||
| Approach angle | (.) | 20 | ||
| Departure angle | (.) | 18 | ||
| Min ground clearance | mm | 220 | ||
Shandong TSD Special Vehicle manufacturing CO.,Ltd locating in China biggest semi trailers production base—Liangshan county, Shandong Province. Here you can get everything regarding to all kinds of semi trailers.
Since 1960s, the General Machinery Plant of China Construction Second Engineering Bureau become an early domestic leading enterprise engaged in the production of powder material transport vehicles, special oilfield vehicles, and construction machinery vehicles.
As a sub branch of GMPC, TSD Special Vehicle keep focus on bulk cement tanks and other semi trailers, With two technology patent of our own, SHENJUN cement tank trailers is sharing almost 1/3 in domestic market and enjoying very good reputation also.
In 2020, the company introduced domestic advanced technology and talents, and cooperated with Zoomlion and Hubei Wuhuan to start production of sanitation vehicles, rod sweepers, rod sprinklers, garbage trucks, fire trucks, truck mounted cranes, ambulances, etc.
The factory has a high-level professional, hard-working and dedicated modern staff team, more than 20 years of exploration and enterprising, and accumulated rich experience in design, development and production.
We warmly welcome all friends to visit our factory any time, learn from each others and improve business, WIN-WIN TOGETHER.
1.You are factory or trading Company?
Yes, we are oversea sales department of TSD automobile. And you are always welcomed to visit our factory.
2.Could your company modify the standard product depends on my request?
Yes. Our company is specialized in researching and designing various of special purpose vehicle and spare parts. We can provide any product according to your demand.
3. Could your company totally customize products for me?
We can provide the customized-designing product meeting with any of your demand.
4. Could you provide certification that we need?
We can provide various certifications associate with trailer and truck. Such as DOT, ADR, SASO and so on.
5. How long could we receive our goods?
It depends on the product that you have ordered. If the goods are prepared, we will deliver your goods as soon as possible.
6. How about the after-sale service?
We can provide you the technical support to guide you require your product. And we will also send original spare parts free of charge by air. If you have special need, we can let our engineer to help you in person
