Home /Products/Highway Road Sweeper/Cloth 3.5 9 10 Ton Electric Water Tank Collection Dump Compress Garbage Removal Compactor Truck Road Sweeper Hook Lift Waste Vehicles

Cloth 3.5 9 10 Ton Electric Water Tank Collection Dump Compress Garbage Removal Compactor Truck Road Sweeper Hook Lift Waste Vehicles

1 set
MOQ
Cloth 3.5 9 10 Ton Electric Water Tank Collection Dump Compress Garbage Removal Compactor Truck Road Sweeper Hook Lift Waste Vehicles
Features Gallery Product Description Request A Quote
Features
Specifications
Steering: Left
Type: Van
Battery Type: Lithium
NEDC Max. Range: 301 ~400 Km
Battery Energy(kWh): 90-110kWh
Battery Warranty: 80000 - 100000 Km
Fast Charge Time(h): ≤1h
Slow Charge Time(h): 6-8h
Total Motor Power(kW): 100-150kW
Total Motor Torque(N.m): 400-500Nm
Total Horsepower(Ps): 150-200Ps
Gear Box: Semi-automatic
Wheelbase: 1500-2000mm
Number Of Seats: 4
Drive: RWD
Front Suspension: Double Wish Bone
Rear Suspension: Double Wish Bone
Steering System: Hydraulic
Parking Brake: Manual
Brake System: Front Drum+Rear Drum
ABS(Antilock Braking System): Yes
ESC(Electronic Stability Control System): Yes
Radar: None
Rear Camera: None
Cruise Control: Normal
Sunroof: None
Roof Rack: Metal
Steering Wheel: Normal
Seats Material: Fabric
Interior Color: Dark
Driver's Seat Adjustment: Manual
Copilot Seat Adjustment: Manual
Touch Screen: None
Car Entertainment System: None
Headlight: LED
Daytime Light: LED
Front Window: Manual
Rear Window: Manual
Exterior Rearview Mirror: Manual Adjustment
Air Conditioner: Manual
Car Fitment: 3.5T, 9T, 12.5T, 18T
Basic Infomation
Payment & Shipping Terms
Packaging Details: wooden
Product Description
Products Description
Specifications
We used Dongfeng special mechanical chassis which have excellent driving performance and reliability. Then we developed the full electric systems including e-motor, controller, battery, VCU, e-steering, e-air condition etc. And we integrated all the electric systems on the Dongfeng chassis to make an amazing electric truck.
3.5T Electric truck parameters
 Dimensions (length × width × height) (mm)
  4900 or 5240×1780×2040
Total weight with full load (kg)
 3495
Chassis weight (kg)
 1550
 Wheelbase (mm)
 2850/3190 (two options)
 Front/rear track (mm)
 1460/1328
 Axle Load(kg)
 1300/2195
 Tire specifications
 185R14LT 6PR (6 strip)
 Battery Cell type
 NCM
 Battery power (kWh)
 53
 Battery pack voltage (V)
 374
 Motor rated / peak torque (N.m)
 110/300 （PMSM motor）
Motor rated / peak power (kW）
 40/80
Driving Distance per charging(km)
 230km; full load constant speed (40km / h)
9T Electric truck parameters
 Dimensions (length × width × height) (mm)
  6238，6738×2150×2370
Total weight with full load (kg)
8995
Chassis weight (kg)
3900
 Wheelbase (mm)
  3300/3800 (two options)
 Front/rear track (mm)
1760/1630
 Axle Load(kg)
3000/5995
 Tire specifications
8.25R16LT 14PR/9.5R17.5 14PR
 Battery Cell type
 LiFePO4
 Battery power (kWh)
158.7
 Battery pack voltage (V)
512
 Motor rated / peak torque (N.m)
  611/1800 （PMSM motor）
Motor rated / peak power (kW）
80/145
Driving Distance per charging(km)
 320km; full load constant speed (40km / h)
Products Real Shot
Show Details
1. We spent 9 months to developed this truck.
2. Finished 100000km testing in China National vehicle testing center.
3. Finished 50000km testing on the road.
4. Completed 56 innovative designs。
5. Obtained the Chinese Government's approved production number EQ1030CACEV(3.5T), EQ1090KACEV(9T), EQ1121KACEV(12.5T), and EQ1181DACEV1(18T).
Standard with electric door and window, central locking, constant speed cruise, automatic brake adjustment, wrapped air seat; Set up more than 10 storage spaces such as cup holders, card slots and storage boxes, and fully utilize the ergonomics MME to bring a
superior driving experience, comfortable and intimate.
More Products
Company Profile
CHENGDU YIWEI NEW ENERGY AUTOMOBILE CO., LTD. is located in Jingrong Town, Chengdu's innovation and entrepreneurship demonstration base. It is a high-tech enterprise specializing in the design of electric chassis for refuse trucks, the development and production of electrical systems, vehicle control, and intelligent networked information technology.
YIWEI AUTOMOBILE actively responds to the battle to defend the blue sky, fulfills its social responsibility and mission,
andcontributes to building a beautiful China with "blue sky, green land and clean water".
We focus on the "standardized electric chassis + personalized top-mounted electrical control program + information platform service" combination of products; deepen the market segmentation of Electric Refuse trucks.
Production Line
Packaging Logistics
FAQ
Q: What is the production time?
A: Normally, the production time is about 35-40 days.

Q: Do you have a warranty on your products?
A: Yes! Normally, our products come with a 1-year warranty.

Q: Do you support customization?
A: Yes, we can design products upon your request.

Q: What are the requirements to be your agent/distributor?
A: We welcome agents from all over the world. Please contact us to know more details.
